SPIPOXY FD PRIMER

SPIPOXY FD PRIMER, based on epoxy / polyamide resin, is an epoxy primer coating for industrial use with good adherence, corrosion resistance, and chemical resistance
Machinery, Construction equipment, general coating on metals
View more

Procedure

1. Surface preparation

  • Surfaces must be clean, dry and free of contamination such as wax, oils, grease, dirt, mill scale or rust. Glossy surfaces
    must be scuff sanded prior to application. Old paint must be tested for solvent resistance.

2. Environmental Conditions

  • Temperature : 5~35oC
  • Relative humidity : up 85%

3. Application Equipment

  • Air / Airless spray, Brush, Roller

Caution for usage

1) Avoid applying paint on rainy days, high humidity (over 80%), low temperature (below 5 °C) and high temperature (over 40 °C surface temperature).

2) Store the product in a dry, cool place at room temperature (5 ~ 35 °C) away from fire and direct sunlight. Keep container tightly closed with the injection port facing upward.

3) Do not mix this product with other paints..

4) After the painting work, please wash exposed skin thoroughly.

5) Dispose of the waste paint through the waste disposal company designated by the Ministry of Environment.efore recoating.

6) Since this product is a chemical product, it may deteriorate during long-term storage. Please use it within the validity period. Please use the product after confirming it with the consumer counseling room.

Safety Precautions for handling

1) Store it indoor (5~35°C) condition, avoiding heat and open flame. And, keep it standing and being closed.

2) Dispose of the waste paint through the waste disposal company designated by the Ministry of Environment.

3) Since this product is a chemical product, it may deteriorate during long-term storage. Please refer to our customer center for the products that have p assed this period.

Warning

Please consult our enclosed herewith warning notice.

Application system

TOP COAT : SPIROLLTAN

View more
Finish Matte Color Wide range
Applied over Steel, FRP Components 2
Volume Solid About 32.45% (White) Recommended Film
Thickness
50 μm
 Coats 1~2 Mixing Ratio
A : B

1:1
Recommended
Coverage
6.49 m2/L (D.F.T 50 μm)
* Allow for application losses and surface
irregularities.
 Pot life(25°C) 6hr
Dry times(25°C)
Set to touch : 15min
Dry hard : 4hr
Recoating time(25°C) Over 6hr ~ Inner 7 day
Diluent Ratio 10 ~ 20% (vol)  Thinner Epocoat 1000 Thinner
Shelf Life 12month (5~38°C)
