SUPERPOXY 270HB (HD)

SUPERPOXY 270HB(HD) is a high-build polyamide epoxy with high solids content designed for industrial and marine use in severe environmental condition. It provides excellent durability in marine atmosphere and economical long-term protection with only one coat.

Intermediate or top coat for tank-exterior, structural steel, piping in chemical plants, box girder and refineries, etc.

View more

Procedure

1. Surface preparation

  • Steel : All primed surfaces must be free of oil, moisture and any other contaminants.
  • Concrete : As a fully cured state and prepare in accordance with blast cleaning or prickling

2. Environmental Conditions

  • Over 5°C is ideal for painting and hardening.
  • The surface temperature must be at least 3°C above the dew point to prevent moisture condensation.
  • Drying time can be different under -5°C.

3. Application Equipment

  • Conventional or airless spray, power mixer, brush
  • Airless spray: Tip size-0.021~0.025inch
  • Output pressure-143atm
  • Recommended thinning ratio: about 30%(Mist) about 20%(Main, airless spray). (*Airless spray data are indicative and subject to adjustment)

3. Application Equipment

  • Conventional or airless spray, power mixer, brush
  • Airless spray: Tip size-0.019~0.021inch Output pressure-2200psi/150atm (*Airless spray data are indicative and subject to adjustment)
  • Recommended thinning ratio : about 5%(Airless spray)

Caution for usage

1) Mix the material according to designed mixing ratio and use after stirring it until uniformly blended. And, Use the mixed paint within pot life.

2) Avoid applying paint on rainy days, high humidity(Over 85%) day, low temperature(Under -5°C) condition.

3) When applied over inorganic zinc, a mist coat is required for removing pinhole and bubbling.

4) Even if you use same product(color, lot), the painting equipment and method(thinning ratio) can cause different color. So, you should check the color before using it.

5) When coating summer season (April~September), ‘SUPERPOXY 270HB(HD) SUMMER TYPE <PART B>’ is recommended.

6) When apply this paint to exposure region, it is possible to occur yellowing and chalking, so you have to apply good weather resistance topcoat.

7) When exposed long time, the chalking can be occurred. So, remove chalking and dust before recoating.

Safety Precautions for handling

1) Store it indoor (5~35°C) condition, avoiding heat and open flame. And, keep it standing and being closed.

2) Dispose of the waste paint through the waste disposal company designated by the Ministry of Environment.

3) Since this product is a chemical product, it may deteriorate during long-term storage. Please refer to our customer center for the products that have p assed this period.

Warning notice

  • Please consult our enclosed here with warning

Application system

  • Preceding primer : SUPERZINC 190BG(D), SUPERZINC 190BG, SUPERPOXY 122, etc.
  • Subsequent topcoat : SUPERTHANE 300BG, SPIFLON(S), etc.
View more
Finish Flat Color Wide range of color
Applied over Primed steel or concrete Components 2
Volume Solid Approximately 75% Recommended Film
Thickness
100~125 μm
 Coats 1~2 Mixing Ratio
A : B

1:1(vol)
Recommended
Coverage
7.5 m2/L ( @ D.F.T. 100μm)
* Allow for application losses and surface
irregularities.
 Pot life(20°C) 6hrs (by 20% thinning)
Dry times(20°C)
(SUMMER TYPE)
Dry through : 8hrs Recoatable(20ºC) To topcoat(min/max) : 8hrs ~ 1months
Diluent KOATHINNER 123S, SUPERTHINNER 123(S) Shelf Life
12months

(When stored indoors at 5~35ºC)
Diluent KOATHINNER 123S, SUPERTHINNER 123(S)  Packing Unit  18L[9L/9L]
