SUPERPOXY 1375

SUPERPOXY 1375 is a polyamide cured epoxy primer with high solids content designed for industrial and marine use in severe environmental condition. It is excellent primer in corrosive environments.

Used as a anticorrosive primer for non-immersion and anticorrosion of steel structures, pipes, tank exteriors, container, etc.
Use SUPERPOXY 130 for immersion.

View more

Procedure

1. Surface preparation

Previously painted by inorganic zinc : All surfaces must be free of moisture, dust of cement, oil and any other contaminants
Severe exposure : Blast in accordance with SSPC-SP10(“Near White”, SA 2 1/2)
Mild exposure: Power tool cleaning in accordance with SSPC-SP3 is acceptable.

2. Environmental Conditions

Over 5°C is ideal for painting and hardening.
The surface temperature must be at least 3°C above the dew point to prevent moisture condensation.
Drying time can be different under -5°C.

3. Application Equipment

Conventional or airless spray, power mixer
Airless spray: Tip size-0.017~0.025 inch
Output pressure-2100psi/143atm
Recommended thinning ratio: about 5~10%(airless spray). (*Airless spray data are indicative and subject to adjustment)

Caution for usage

1) Mix the material according to designed mixing ratio and use after stirring it until uniformly blended. And, Use the mixed paint within pot life.

2) Avoid applying paint on rainy days, high humidity(Over 85%) day, low temperature(Under -5°C) condition.

3) When applied over inorganic zinc, a mist coat is required for removing pinhole and bubbling.

4) Even if you use same product(color, lot), the painting equipment and method(thinning ratio) can cause different color. So, you should check the color before using it.

5) When coating summer season (April~September), ‘SUPERPOXY 270HB(HD) SUMMER TYPE <PART B>’ is recommended.

6) When apply this paint to exposure region, it is possible to occur yellowing and chalking, so you have to apply good weather resistance topcoat.

7) When exposed long time, the chalking can be occurred. So, remove chalking and dust before recoating.

Safety Precautions for handling

1) Store it indoor (5~35°C) condition, avoiding heat and open flame. And, keep it standing and being closed.

2) Dispose of the waste paint through the waste disposal company designated by the Ministry of Environment.

3) Since this product is a chemical product, it may deteriorate during long-term storage. Please refer to our customer center for the products that have p assed this period.

Warning notice

Please consult our enclosed here with warning

Application system

Preceding primer(if necessary) : SUPERZINC 190BG Series

Subsequent topcoat : SUPERPOXY Series, SUPERTHANE Series, SPIFLON Series

View more

Finish	Flat	Color	Grey and Others
Applied over	Primed steel or Blasted steel	Components	2
Volume Solid	Approximately 75%	Recommended Film Thickness	50~100 μm
Coats	1	Mixing Ratio A : B	1:1(vol)
Recommended Coverage	10.0 m2/L ( @ D.F.T. 75μm) * Allow for application losses and surface irregularities.	Pot life(20°C)	4hrs (by 25% thinning)
Dry times(20°C) (SUMMER TYPE)	Dry through : 8hrs	Recoatable(20ºC)	To topcoat(min/max) : 8hrs ~ 1months
Diluent	KOATHINNER 123S, SUPERTHINNER 123(S)	Shelf Life	12months (When stored indoors at 5~35ºC)
Packing Unit	16L[8L/8L]

View more
